A.6 UnCLIP Evaluation
Previous fMRI-to-image papers (Scotti et al., 2023; Ozcelik and VanRullen, 2023; Mai and Zhang, 2023) opted for Versatile Diffusion because it was state-of-the-art in reconstructing images from CLIP image latents with little variation. To compare the image generation capabilities of our unCLIP model with Versatile Diffusion, we computed Fréchet inception distance (FID) (Heusel et al., 2018) scores across 30,000 randomly sampled images from the COCO 2017 validation set. The images were center-cropped and scaled to 480 × 480 resolution. For Versatile Diffusion, we used Huggingface’s VersatileDiffusionDualGuidedPipeline with text_to_image set to 0 to not take any input from text.
Our unCLIP model fine-tuned from Stable Diffusion XL outperforms Versatile Diffusion in terms of returning the original image from CLIP latents (see Appendix 9). This difference is visually obvious as shown in Figure 9. Note that while we observed distortions in our unrefined fMRI-toimage reconstructions using our unCLIP model fine-tuned from SDXL, such distortions were rare when using the ground truth CLIP embeddings.
The ability for this unCLIP model to nearly perfectly return the original image also indicates that OpenCLIP ViT-bigG image embeddings effectively preserve the majority of the information inherent in the original pixel image, retaining both low-level structure and high-level semantic details.
This paper is available on arxiv under CC BY 4.0 DEED license.
Authors:
(1) Paul S. Scotti, Stability AI and Medical AI Research Center (MedARC);
(2) Mihir Tripathy, Medical AI Research Center (MedARC) and a Core contribution;
(3) Cesar Kadir Torrico Villanueva, Medical AI Research Center (MedARC) and a Core contribution;
(4) Reese Kneeland, University of Minnesota and a Core contribution;
(5) Tong Chen, The University of Sydney and Medical AI Research Center (MedARC);
(6) Ashutosh Narang, Medical AI Research Center (MedARC);
(7) Charan Santhirasegaran, Medical AI Research Center (MedARC);
(8) Jonathan Xu, University of Waterloo and Medical AI Research Center (MedARC);
(9) Thomas Naselaris, University of Minnesota;
(10) Kenneth A. Norman, Princeton Neuroscience Institute;
(11) Tanishq Mathew Abraham, Stability AI and Medical AI Research Center (MedARC).
